WIRELESS
Working Modes Range Extender/Access Point
HARDWARE FEATURES
- Plug Type EU, UK, US
- Interface 1 x 10/100M Ethernet Port (RJ45)
- Ports 1 x 10/100Mbps Ethernet Port (RJ45)
- Button RE (Range Extender) Button, Reset Button
- Input Power 100-240V~50/60Hz
- Power Consumption About 3W
- Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
- Dimensions ( W x D x H ) 4.3 x 2.6 x 3.0 in. (110.0 x 65.8 x 75.2mm)
- Antenna 2 x internal
WIRELESS FEATURES
- Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
- Frequency 2.4~2.4835GHz
- Signal Rate 11n: Up to 300Mbps (dynamic)
- 11g: Up to 54Mbps (dynamic)
- 11b: Up to 11Mbps (dynamic)
- Working Modes Range Extender/Access Point
- Reception Sensitivity 270M: -68dBm@10% PER
- 130M: -68dBm@10% PER
- 108M: -68dBm@10% PER
- 54M: -68dBm@10% PER
- 11M: -85dBm@8% PER
- 6M: -88dBm@10% PER
- 1M: -90dBm@8% PER
- Transmit Power < 20 dBm (EIRP)
- Wireless Modes Range Extender/Access Point
- Wireless Functions WMM (Wi-Fi Multimedia)
- Wireless MAC Address Filtering
- Wireless Statistic
- Domain Login Function
- Wireless Security 64/128/152-bit WEP
- WPA-PSK / WPA2-PSK
- Transmission Power < 20 dBm (EIRP)
OTHERS
- Certification CE, RoHS
- Package Contents 300Mbps Universal Wi-Fi Range Extender TL-WA850RE
- Quick Installation Guide
- System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac® OS, NetWare®, UNIX® or Linux.
- Environment Operating Temperature: 0°C~40°C (32°F~104°F)
- Storage Temperature: -40°C~70°C (-40°F~158°F)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
